Nantong Sanjing Chemglass Co.,Ltd
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | NTSJ |
| Certification: | CE,ISO9001 |
| Model Number: | FPGR-20 |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case. |
| Delivery Time: | within 5days after payemnt received |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500 sets/momth |
| Material: | 3.3 Borosilicate Glass | Stock: | In Stock |
|---|---|---|---|
| Warranty: | 1 Year | Certification: | CE/ISO |
| After-sales Service Provided: | Video Technical Support、Field Maintenance And Repair Service | Vacuum Degree: | -0.098mpa |
| Automatic Grade: | Semi-Automatic | Type: | Reaction Kettle |
| Application: | New Material Synthesis | ||
| High Light: | chemical stirred tank reactor,laboratory rotary evaporator |
||
PTFE flush discharge valve: No-sample accumulation in valve during operation and discharge.
Side discharge valve (standard or preload): No dead angle, air isolated discharge.
Preload discharge valve is able to decrease flask crack risk due to improper over-screw of discharge valve.
Adapter of glass reactor jacketed layer:
The liquid of the flow circulating pump or high & low temperature circulating pump will through the adapter firstly, and then into the glass reactor body, help to ease the pressure of the glass, finally prolong the service life of the glass body.
Glass reactor lid could be customized
ISO & CE certification high quality guarantee
| Product Model | PGR-3 | PGR-5 | PGR-10 | PGR-30 | PGR-50 | PGR-100 | PGR-200 |
| Volume(L) | 3 | 5 | 10 | 30 | 50 | 100 | 200 |
| Neck No.on Cover | 4 | 5 | 6 | 6 | 6 | 6 | 6 |
| External Diameter of Inner Vessel(mm) | 150 | 180 | 230 | 330 | 365 | 460 | 600 |
| External Diameter of Outer Vessel(mm) | 200 | 230 | 290 | 365 | 410 | 500 | 650 |
| Cover Diameter(mm) | 150 | 180 | 265 | 265 | 265 | 340 | 340 |
| Vessel Height(mm) | 300 | 400 | 450 | 730 | 850 | 950 | 1200 |
| Motor Power(W) | 40 | 60 | 140 | 140 | 140 | 250 | 750 |
| Vacuum Degree(Mpa) | 0.098 | 0.098 | 0.098 | 0.098 | 0.098 | 0.098 | 0.098 |
| Rotation Speed(rpm) | 50-1400 | 50-600 | 50-600 | 50-600 | 50-600 | 50-600 | 50-600 |
| Torque(Nm) | 0.27 | 0.95 | 2.23 | 2.23 | 2.23 | 3.98 | 6.37 |
| Power(V) | 220 | 220 | 220 | 220 | 220 | 220 | 220 |
| Dimension(mm) | 320*350*900 | 450*450*1200 | 650*650*1900 | 700*500*2100 | 800*600*2300 | 1000*700*2700 | 1200*900*3200 |
Customizable
All flasks are made of 3.3 borosilicate glass
Vacuum-jacketed distillation adaptor
Carefully designed 3-way cow adapter
The cold trap protects the vacuum pump from contamination and damage of vapors.
For organic chemistry labs, distillation, fractional distillation, separation, purification, and synthesis.
We are located in Nantong City, with convenient transportation access. 2 hours away drives from Shanghai. Covering an area of sixteen thousand square meters, now we have over one hundred employees, boast an annual sales figure that exceeds US dollars twenty million.
Advantage of us is customize according to client need. We can provide relevant industry with design, manufacturing, equipment selection, instrument supporting, installation, debugging, maintenance. Our chemical glass instruments have been widely used in the fields of pharmaceuticals, chemicals, biological pharmacy, new material, noble material.
Flexible and multiply shipping methods for on-time shipment:
We have good cooperation with many international express companies, such as DHL/ UPS/ FedEx/ TNT and other, as well as large shipping companies providing air shipping and sea shipping.
Strict packing process to ensure the safety and completeness of the goods
Customizable
1) Professional consultation service on System Configuration to meet user's real needs.
2) We offer experimental site for buyers with special needs, do experiment with customers so to ensure suitability
3) production & On-time delivery: Products are test by many indexes before shipping, Lead time will be strictly controlled.
4) Post-sales direction on product application: Offer free guidance on products operation, help user to improve research accuracy, efficiency and extend product service life by much.
5) Repair and maintenance support: Strong ability on remote trouble shot guidance. Oversea buyers are able to solve problem in short time.
6) Rich parts supply : Rich parts available even for past instruments.
