| MOQ: | 1 set |
| Price: | Negotiable |
| Standard Packaging: | The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case. |
| Delivery Period: | within 5days after payemnt received |
| Payment Method: | L/C, D/A, D/P, T/T, Western Union, |
| Supply Capacity: | 500 sets/momth |
50L Chemglass Jacketed Reactor Stainless Steel Chemglass Reaction Vessel designed for precision chemical processing in industrial applications.
| Product Model | PGR-3 | PGR-5 | PGR-10 | PGR-30 | PGR-50 | PGR-100 | PGR-200 |
|---|---|---|---|---|---|---|---|
| Volume (L) | 3 | 5 | 10 | 30 | 50 | 100 | 200 |
| Neck No. on Cover | 4 | 5 | 6 | 6 | 6 | 6 | 6 |
| External Diameter of Inner Vessel (mm) | 150 | 180 | 230 | 330 | 365 | 460 | 600 |
| External Diameter of Outer Vessel (mm) | 200 | 230 | 290 | 365 | 410 | 500 | 650 |
| Cover Diameter (mm) | 150 | 180 | 265 | 265 | 265 | 340 | 340 |
| Vessel Height (mm) | 300 | 400 | 450 | 730 | 850 | 950 | 1200 |
| Motor Power (W) | 40 | 60 | 140 | 140 | 140 | 250 | 750 |
| Vacuum Degree (Mpa) | 0.098 | 0.098 | 0.098 | 0.098 | 0.098 | 0.098 | 0.098 |
| Rotation Speed (rpm) | 50-1400 | 50-600 | 50-600 | 50-600 | 50-600 | 50-600 | 50-600 |
| Torque (Nm) | 0.27 | 0.95 | 2.23 | 2.23 | 2.23 | 3.98 | 6.37 |
| Power (V) | 220 | 220 | 220 | 220 | 220 | 220 | 220 |
| Dimension (mm) | 320*350*900 | 450*450*1200 | 650*650*1900 | 700*500*2100 | 800*600*2300 | 1000*700*2700 | 1200*900*3200 |
The glass reactor systems are essential equipment for mixing, reaction, distillation and filtration in chemistry and pharmaceutical industries. We offer a wide range of glass reactors with volumes from 250mL to 250L, available in electrical or air-driven configurations, desktop or floor-stand models, with or without filter base.
All glass reactor systems can be modified in our factory for custom dimensions, motor power, explosion proof requirements, additional glassware, and customized port sizes.
Packaging: Glass components wrapped with foam and carton, main body portion packed in wooden cases. Both neutral and customized packaging available.
Shipping: International Express services including DHL, UPS, TNT, EMS. Option to use your own shipping agent available.
Established in 2006, Nantong Sanjing Chemglass Co., Ltd. specializes in research, development and production of chemical glass instruments. Our product range includes glass reactors, wiped film evaporators, rotary evaporators, short-path molecular distillation devices, and chemical glass tubes.
Our core advantage lies in customizing solutions according to client requirements. We provide comprehensive services including design, manufacturing, equipment selection, instrument supporting, installation, debugging, and maintenance. Our chemical glass instruments are widely used in pharmaceuticals, chemicals, biological pharmacy, new materials, and noble materials industries.
Located in Nantong City with convenient transportation access (2 hours from Shanghai), our 16,000 square meter facility employs over 100 professionals and achieves annual sales exceeding $20 million.
|
|
