Moveable Design Jacketed Glass Reactor Vessel Explosion Proof G3.3 Borosilicate

MOQ: 1 set
Price: Negotiable
Standard Packaging: The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case.
Delivery Period: within 5days after payemnt received
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 500 sets/momth
Details Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
NTSJ
Certification
CE,ISO9001
Model Number
FPGR-50
Type:
Reaction Kettle
Warranty:
OneYear
Dimension(l*w*h):
Ordered Equipment
Voltage:
Customizable As Clients' Region
Automatic Grade:
Semi-Automatic
Application:
Lab Stirring, Distillation
Condition:
New
Glass Material:
Borosilicate Glass 3.3
Highlight:

laboratory reactor vessel

,

borosilicate glass reactor

Product Description

Glass Reactor Laboratory

The glass reactor can work under nature pressure or negative pressure.


Jacketed Reactor that is Double Layer Glass Reactor which means there are interlayer between inner layer and outer layer.
This Interlayer can pass through heating or cooling source.



Based on those heating or cooling source, the material or solvent in the glass reaction vessel will be heated or cooled.
The Glass Reactor can be used for stirring ,mixing, distillation and extraction so it is widely use as modern chemistry, biochemical, pharmacy and the advanced synthetic.



Main features

Customizable

Main reactor body is made by G3.3 borosilicate glass. It can support chemical reaction temperature from -120 to 300 centigrade.

Machine has a 304 stainless steel frame and moveable design. There are at least 5 preformed holes on the lid, which can help processing of liquid recycling, flowing in, temperature measuring, liquid adding, etc.





Glass reactor can work under vacuum and constant pressure. In quiescent state, vacuum rate of its inner space can reach -0.098MPa.

Stirring hole of the lid will be sealed by alloy steel mechanical sealing part. Connector is adopted PTFE material. Both of them will guarantee the vacuum rate of reactor inside space.

PT100 temperature sensor, which is a high precision temperature measuring tool.




Product Model

Volume(L)

Neck No.on Cover

External
Diameter of
inner Vessel(mm)

External
Diameter of
outer Vessel(mm)

Cover Diameter

Vessel Height(mm)

Motor Power(w)

Vacuum Degree(Mpa)

Rotation
Speed(rpm)

Torque(Nm)

Power(V)

Dimension(mm)
PGR-3
3
4
150
200
150
300
40
0.098
50-1400
0.27
220
320*350*900
PGR-10
10
6
230
265
450
140
0.098
50-600
2.23
220
650*650*1900
PGR-50
50
6
365
410
265
850
140
0.098
50-600
2.23
220
800*600*2300
PGR-100
100
6
460
500
340
950
250
0.098
50-600
3.98
220
1000*700*2700
PGR-200
200
6
600
650
340
1200
750
0.098
50-600
6.37
220
1200*900*3200




Moveable Design Jacketed Glass Reactor Vessel Explosion Proof G3.3 Borosilicate 0

Our factory

Nantong Sanjing Chemglass Co . Ltd's main products are : glass reactor series , rotary evaporator chemical glass pipes , glass condenser series , glass reaction devices series , bath pots series , heating circulator series , thermostatic bath series , cooling circulator series , constant speed stirrer , water circulation vacuum pumps , lab consumables and other products which are widely used in pharmaceuticals , chemicals , biological pharmacy , new materials , noble metals and other files , meanwhile.





Moveable Design Jacketed Glass Reactor Vessel Explosion Proof G3.3 Borosilicate 1

Packing and delivery


-The glass parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Customized packaging can be available.




-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on.Besides,you can choose to use your own shipping agent.

Our service

Customizable



How long is your delivery time?
Generally it is within 3 working days after receiving the payment if the goods are in stock. Or it is 5-10 working days if the goods are not in stock, depending on order quantity.



How to solve the equipment trouble during using ?
Please email us about problem with pictures or a small video,we will find the problem and solve it. If broken, we will send you a new free part if in the warranty period.


How to choose suitable equipment ?
tell us your work flow and requirements ,then we will recommend you suitable equipment according to your requirements, application experience and feedback from our clients.
