| MOQ: | 1 SET |
| Price: | Negotiable |
| Standard Packaging: | polywood case |
| Delivery Period: | 20 working days |
| Payment Method: | T/T, Western Union, L/C |
| Supply Capacity: | 100 sets per month |
It is a stilling method under high vacuum. The average free path of steam molecular is less than the distance between evaporating surface and condensing surface. Components in the mixing liquid will be separated according to different evaporating rate.
It is a special liquid-liquid separating technology. Its working principle is advanced more than traditional boiling point separating method. Supporting by this technology, our SPD series short path molecular distillation device is a high efficient plant essential oil refining equipment. It can help you get highly purified essential oil.
| Model | MD-80 | MD-100 | MD-150 | MD-200 |
| Feed Rate(kg/hr) | 1.0-20 | 1.5-30 | 2.5-40 | 3.5-70 |
| Estimate Throughput at End of 8-10 hr/day for CBD (kg) | 8 | 12 | 20 | 28 |
| Effective Evaporationn Area(m2) | 0.1 | 0.15 | 0.25 | 0.35 |
| Motor Power (W) | 120 | 120 | 120 | 120 |
| Maximum Speed(rpm) | 350 | 350 | 350 | 350 |
| Barrel Diameter (mm) | 80 | 100 | 150 | 200 |
| Feeding Funel Volume( L) | 1 | 2 | 3 | 5 |
| Dimension(DXWXH mm) | 2120X1740X628 | 2120X1740X628 | 2270X1940X628 | 2420x2040x628 |
| Internal Condenser Area(m) | 0.2 | 0.3 | 0.4 | 0.5 |
| Jacketed Feeding Vessel Volume ( L) | 1 | 2 | 3 | 5 |
| Distillate Receiving Vessel Volume(L) | 1 | 2 | 5 | 5 |
| Residue Receiving Vessel Volume(L) | 1 | 1 | 3 | 5 |
| Wiper | PTFE scraper | PTFE scraper | PTFE scraper | PTFE scraper |
Molecular distillation system is composed of high borosilicate glass 3.3, stainless steel and PTFE, so it has excellent anti-corrosion ability.
The main part of the molecular distillation system is made of high borosilicate glass 3.3, and the whole operation process can be well observed.
The high precision distillation cylinder body enables the liquid to form a complete integrated film on the heating surface.The inner wall of the barrel body is smooth and bright, not easy to stick to the material and scaling.
imported brand variable frequency speed reduction motor,safe and reliable in operation;equipped with self-cooling fan,it can continuous working for a long time.
We are located in Nantong City, 2 hours away drives from Shanghai. Covering an area of sixteen thousand square meters, now we have over one hundred employees, boast an annual sales figure that exceeds US dollars twenty million.
Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching America, Mexico, India, Turkey, Germany and Norway. Besides this, we also build the relationship with more than 10 oversea agents.
Wooden box with sufficient inner protection for short path distillation unit; Besides,will buy insurance for every shipment by sea or by air.
1 year complimentary warranty
Training how to install the machine and how to
operate
Free lifetime maintenance service and 24-hour
technical support
Reliable quality and thoughtful after sale service
|
|
