30 L High Efficient Jacketed Glass Reaction Kettle With Condenser

30 L High Efficient Jacketed Glass Reaction Kettle With Condenser
30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 30 L High Efficient Jacketed Glass Reaction Kettle With Condenser
Basic Information
Place of Origin: CHINA
Brand Name: NTSJ
Certification: CE,ISO9001
Model Number: FPGR-10
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case.
Delivery Time: within 5days after payemnt received
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 sets/momth
Get Best Price Contact Now Chat Now
  • Detail Information
  • Product Description
Vacuum Degree: 0.098mpa Automatic Grade: Semi-Automatic
Certification: ISO9001 Type: Reaction Kettle
After-sales Service Provided: Video Technical Support,Field Maintenance And Repair Service Application: New Material Synthesis
High Light:

double jacketed glass reactor

,

single layer glass reactor

,

pharmaceutical industry glass reactor vessel

Glass Reactor

The glass reactor systems are the essential equipment for mixing, reaction, distillation and filtration in chemistry and pharmaceutical industries.
We offer a wide range of glass reactors with volumes from 250mL to 250L. They are electrical or air-driven, desktop or floor-stand, with or without filter base.



Product Model PGR-3 PGR-5 PGR-10 PGR-30 PGR-50 PGR-100 PGR-200
Volume(L) 3 5 10 30 50 100 200
Neck No.on Cover 4 5 6 6 6 6 6
External Diameter of Inner Vessel(mm) 150 180 230 330 365 460 600
External Diameter of Outer Vessel(mm) 200 230 290 365 410 500 650
Cover Diameter(mm) 150 180 265 265 265 340 340
Vessel Height(mm) 300 400 450 730 850 950 1200
Motor Power(W) 40 60 140 140 140 250 750
Vacuum Degree(Mpa) 0.098 0.098 0.098 0.098 0.098 0.098 0.098
Rotation Speed(rpm) 50-1400 50-600 50-600 50-600 50-600 50-600 50-600
Torque(Nm) 0.27 0.95 2.23 2.23 2.23 3.98 6.37
Power(V) 220 220 220 220 220 220 220
Dimension(mm) 320*350*900 450*450*1200 650*650*1900 700*500*2100 800*600*2300 1000*700*2700 1200*900*3200



Main features

Customizable

1. high-borosilicate glass with nice physical-chemical properties; Resistant to strong acidic properties of materials; only touching with glass parts & PTFE, no cross-contamination.


2. Double cylinder; kettle cover is separated from kettle body. It is convenient to disassemble, clean and install.


3. Stirring adopts to mechanical sealing, it keeps higher vacuum degree among the same products in the market. It also keeps high vacuum degree when stirring.


4. Glass(PTFE)discharge valve, non-dead angle mixing, fast emptying, no residue.


5. Frequency control speed gear motor, smooth running,high torque, automatic booster, no spark, noise free, long life.


6. SUS frame and cast aluminum material kettle body support, elegant appearance, stable structure.



7. Circulating water/oil bath, high and low temperature machine can supply heating source; Cooling machine:cooling chiller,high and low temperature machine,convenient and practical

Product Details

30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 0

30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 1



Packing and delivery

The damage caused by the transportation problem shall be born by the seller.
We are experienced in the whole packing and shipping process, and we will be responsible for any damage made during shipping and sending clients replacements for free.
Strict packing process to ensure the safety and completeness of the goods.



30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 2

Our factory

Established in 2006, Nantong Sanjing Chemglass Co., Ltd. is a manufacturer and trader specialized in research, development and production of chemical glass instrument. Main products include glass reactor, wiped film evaporator, rotary evaporator, short-path molecular distillation device and chemical glass tube.



Advantage of us is customize according to client need. We can provide relevant industry with design, manufacturing, equipment selection, instrument supporting, installation, debugging, maintenance. Our chemical glass instruments have been widely used in the fields of pharmaceuticals, chemicals, biological pharmacy, new material, noble material.



30 L High Efficient Jacketed Glass Reaction Kettle With Condenser 3

Our services

Customizable

Engineers available to service machinery overseasEngineers available to service machinery overseas
Reliable quality and thoughtful after sale serviceEngineers available to service machinery overseas
We are a professional manufacturer which is specialized in designing, producing and selling.Engineers available to service machinery overseas
We have obtained many patents at home and abroad, all of our products is being innovated all the time.Engineers available to service machinery overseas
We are able to do ODM.
