10L 20L 30L 50L Lab Glass Reactor , Glass Reactor Vessel Corrosion Resistent

MOQ: 1 set
Price: Negotiable
Standard Packaging: The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case.
Delivery Period: within 5days after payemnt received
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 500 sets/momth
Details Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
NTSJ
Certification
CE,ISO9001
Model Number
FPGR-50
Weight:
68kg ~ 190kg
Warranty:
1 Year
Pipe Fitting Material:
304 Stainless Steel
Vacuum Degree:
0.098mpa
Automatic Grade:
Semi-Automatic
Voltage:
220V
Certification:
CE,ISO9001
Application:
Lab Stirring, Distillation
Dimension(l*w*h):
Ordered Equipment
Feature:
Customized
Highlight:

glass pressure reactor

,

double layer glass reactor

,

50l glass reactor vessel

Product Description

Glass Reactor Laboratory

Double layers series glass reactors are mainly used in pharmaceutical, chemical and biological experiment and production.We can customized products according to the actual needs of you.They can be used in various low and high temperature reaction. They can be used alone or in combination with vacuum pumps, cryogenic coolant circulation pumps, high and low temperature circulation pumps and high temperature oil baths.



10L 20L 30L 50L Lab Glass Reactor , Glass Reactor Vessel Corrosion Resistent 0



Main features

Constant rotate speed, no electric brush, no spark, safe and stable, enable continuous working.
Full set of glass part is produced by G3.3 borosilicate glass, owns excellent chemical and physical properties.
When glass interlayer connecting to hot oil and been circulated, it can do heating reaction, connecting to refrigerating fluid can do low temperature reaction.
Enable reaction under normal temperature, that is connecting to tap water can take away the reaction heat quickly.
Be able to work under normal and negative pressure, negative pressure up to -0.098MPa.
Alternating current dynamo conducts frequency control stirring, reliable operation, large moment of force and no spark.
The inner core of stirring rod is made from 321 stainless steel, strengthened anti-corrosion property, military technology makes workmanship more exquisite, operation with high proficiency.

Customized




Product Model

Volume(L)

Neck No.on Cover

External
Diameter of
inner Vessel(mm)

External
Diameter of
outer Vessel(mm)

Cover Diameter

Vessel Height(mm)

Motor Power(w)

Vacuum Degree(Mpa)

Rotation
Speed(rpm)

Torque(Nm)

Power(V)

Dimension(mm)
PGR-3
3
4
150
200
150
300
40
0.098
50-1400
0.27
220
320*350*900
PGR-10
10
6
230
265
450
140
0.098
50-600
2.23
220
650*650*1900
PGR-50
50
6
365
410
265
850
140
0.098
50-600
2.23
220
800*600*2300
PGR-100
100
6
460
500
340
950
250
0.098
50-600
3.98
220
1000*700*2700
PGR-200
200
6
600
650
340
1200
750
0.098
50-600
6.37
220
1200*900*3200

Product Details

10L 20L 30L 50L Lab Glass Reactor , Glass Reactor Vessel Corrosion Resistent 1



Packing and delivery

Packaging
Glass parts will be wrapped with foam, then put into the carton, the mainbody portion will be packed in wooden cases
Both neutral and customized packaging can be available.
Shipping
We can ship the goods to you by International Express such as DHL, UPS, TNT, EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides, you can choose to use your own shipping agent.



10L 20L 30L 50L Lab Glass Reactor , Glass Reactor Vessel Corrosion Resistent 2

Our factory

Nantong Sanjing Chemglass Co . Ltd is one of largest professional manufacturers of chemical glass equipments in China.The company specializes in design , production and manufacturing of biological and chemical testing instruments and pharmaceutical glass equipments , main products are : glass reactor series , rotary evaporator chemical glass pipes , glass condenser series , glass reaction devices series , bath pots series , heating circulator series , thermostatic bath series , cooling circulator series , constant speed stirrer , water circulation vacuum pumps , lab consumables and other products.

10L 20L 30L 50L Lab Glass Reactor , Glass Reactor Vessel Corrosion Resistent 3



Our service

Customized

On-site installation for big models or batch products
Free factory training for users of customer side on instrument installation and maintenance information.
Complete set of using manuals, technical documents, etc are Provided.
Sufficient spare parts or consumables are available to meet users urgent requests.
