Biodiesel Processing Double Layer Glass Reactor , Glass Reactor Laboratory Cycle Heating Cooling

MOQ: 1 set
Price: Negotiable
Standard Packaging: The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case.
Delivery Period: within 5days after payemnt received
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 500 sets/momth
Details Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
NTSJ
Certification
CE,ISO9001
Model Number
FPGR-50
Dimension(l*w*h):
Ordered Equipment
Frame Material:
Stainless Steel
Certification:
CE/ISO
Feature:
Eco-Friendly
Neck No. On Lid:
Customized
Vacuum Degree:
-0.098mpa
Type:
Reaction Kettle
Highlight:

double jacketed glass reactor

,

borosilicate glass reactor

,

ISO9001 double layer glass reactor

Product Description

Jacketed reactor

Double glass reactor double glass design, inner into reaction menstruum do stirring reaction, interlayer can pass different cold sources (cryoprotectants, hot water or hot oil) do cycle heating or cooling reaction. Setting thermostat conditions, in confined glass reactor, can use require atmospheric or negative pressure conditions conducted stirring response and do reaction solution reflux and distillation is modern Fine Chemical Factory, biopharmaceuticals and new materials synthesized ideal test production equipment.





Product Model PGR-3 PGR-5 PGR-10 PGR-30 PGR-50 PGR-100 PGR-200
Volume(L) 3 5 10 30 50 100 200
Neck No.on Cover 4 5 6 6 6 6 6
External Diameter of Inner Vessel(mm) 150 180 230 330 365 460 600
External Diameter of Outer Vessel(mm) 200 230 290 365 410 500 650
Cover Diameter(mm) 150 180 265 265 265 340 340
Vessel Height(mm) 300 400 450 730 850 950 1200
Motor Power(W) 40 60 140 140 140 250 750
Vacuum Degree(Mpa) 0.098 0.098 0.098 0.098 0.098 0.098 0.098
Rotation Speed(rpm) 50-1400 50-600 50-600 50-600 50-600 50-600 50-600
Torque(Nm) 0.27 0.95 2.23 2.23 2.23 3.98 6.37
Power(V) 220 220 220 220 220 220 220
Dimension(mm) 320*350*900 450*450*1200 650*650*1900 700*500*2100 800*600*2300 1000*700*2700 1200*900*3200



Main features

Customizable

Rugged steel-reinforced PTFE stirrer with anchor agitator which is suitable for a wide range of material viscosity.


Frequency-conversion stirring system + PTFE seal & bearing system.


Digital display and control.



Explosion-proof type is optional.





Biodiesel Processing Double Layer Glass Reactor , Glass Reactor Laboratory Cycle Heating Cooling 0



Packing and delivery

Wooden box packaging products parts and accessories,It can protect all parts.



Sufficient inner protection with different materials, including bubble bag, foam board,etc.


Customizing according to the customers' request.

Our factory

Nantong Sanjing Chemglass Company summarize:Established in 2006, Nantong Sanjing Chemglass Co., Ltd. is a manufacturer and trader specialized in research, development and production of chemical glass instrument. Main products include glass reactor, wiped film evaporator, rotary evaporator, short-path molecular distillation device and chemical glass tube.

Advantage of us is customize according to client need. We can provide relevant industry with design, manufacturing, equipment selection, instrument supporting, installation, debugging, maintenance.

Biodiesel Processing Double Layer Glass Reactor , Glass Reactor Laboratory Cycle Heating Cooling 1

Our service

Customizable

Provide free technical advice.



The seller can provide detailed equipment parameters and configuration list.



The warranty period of the company's products is 12 months from the date of acceptance of the equipment (excluding glass fitings andconsumables).



If there are quality problems in the parts during the warranty period,the seller can provide free replacement of malfunction components;if the damage is due to human factors, when the parts need to bereplaced, the seller will provide the accessories and charge themaintenance cost.
