Food Pharmaceutical 2l Rotary Evaporator , Rotary Film Evaporator Convenient

Food Pharmaceutical 2l Rotary Evaporator , Rotary Film Evaporator Convenient

MOQ: 1 set
Price: Negotiable
Standard Packaging: The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case.
Delivery Period: within 5days after payemnt received
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 500 sets/momth
Detail Information
Place of Origin
CHINA
Brand Name
NTSJ
Certification
CE ,ISO9001
Model Number
FPGR-100
Sealing:
PTFE Sealing
Condenser:
Vertical
Warranty:
One Year
Voltage:
220V
Condition:
New
Process:
Vacuum Distillation
After-sales Service Provided:
Video Technical Support
Application:
Industrial Rotary Evaporator
High Light:

rotary vacuum flash evaporator

,

rotary vacuum film evaporator

,

vacuum distillation 2l rotary evaporator

Product Description

Vacuum Rotary evaporator

The principle is that under the vacuum condition, the constant temperature heats ,making the rotating bottle rotate at a constant speed, the material forms a large area of film on the bottle wall, and then solvent evaporates efficiently. The solvent vapor is cooled by the high efficiency glass condenser and recycled in the collection bottle, which greatly improves the evaporation efficiency.
It is an evaporating instrument widely used in laboratory.It is suitable for reflux operation, rapid evaporation of solvent, concentration of trace components and reaction processes requiring stirring.
Rotary evaporator is mainly used for concentration, crystallization, drying, separation and solvent recovery in pharmaceutical, chemical and biological pharmaceutical industries.

Features

A. Adopt advanced frequency converter and electronic speed regulator to ensure the stable working of motor and improve the evaporation and recovery speed.

B. Explosion-proof rotary evaporator uses a explosion-proof motor, that will keep reaction to be safe in the whole process.

C. Automatic bath lift and vacuum feeding can help to reduce the breakage of rotary flask.

D. Intelligent temperature control can work with both water and oil bath, more widely used. Temperature fluctuation is only ±0.02 ℃, Evaporation is more stable and material can not be washed easily.




Product Model

Evaporation Flask

Receiving Flask

Motor Power(w)

Bath Power

Rotation Speed

Evaporation Speed(L/h)

Power(V)

Dismension(cm)
PR-2
2L/29#
1L
40
1.5
10-180
1.2
220
55*35*75
PR-5
5L/50#
2L/3L
90
2
10-90
2
220
55*35*110
PR-10
10L/95#
5L
120
3
5-110
3.5
220
100*50*180
PR-20
20L/95#
10L+5L
120
5
5-110
5
220
110*70*200
PR-50
50L/125#
10L+10L
180
5
5-110
8
220
120*80*220

Food Pharmaceutical 2l Rotary Evaporator , Rotary Film Evaporator Convenient 0
Packing and delivery

The glass parts will be wrapped with foam material,then put into the carton, all parts will be packed into wooden case finally; Customized packaging can be available.

We are experienced in the whole packing and shipping process, and we will be responsible for any damage made during shipping and sending clients replacements for free.

Food Pharmaceutical 2l Rotary Evaporator , Rotary Film Evaporator Convenient 1

Our factory

Advantage of us is customize according to client need. We can provide relevant industry with design, manufacturing, equipment selection, instrument supporting, installation, debugging, maintenance. Our chemical glass instruments have been widely used in the fields of pharmaceuticals, chemicals, biological pharmacy, new material, noble material.

We are looking forward to forming successful business relationship with new clients around the world in the near future.

Food Pharmaceutical 2l Rotary Evaporator , Rotary Film Evaporator Convenient 2

Our services

About delivery

FOB/ CIF /Door to Door/By air as you like.

About warranty

1 year complimentary warranty

About quantity

Any quantity is acceptable for your order. And the price is negotiable for large quantity.

About customization

 We can provide all kinds of customized services.
We are a manufacturer that can provide all kinds of customized services.
