10 20l 50l Rotary Evaporator Distillation Motorized Mechanism High Safety

MOQ: 1 set
Price: Negotiable
Standard Packaging: The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case.
Delivery Period: within 5days after payemnt received
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 500 sets/momth
Details Information
Product Description
Detail Information
Place of Origin
CHINA, JIANGSU
Brand Name
NTSJ
Certification
CE,ISO9001
Model Number
FPGR-20
Application:
Pharmaceutical Processing
Process:
Evaporator
Weight:
Depending
Condition:
New
Dimension(l*w*h):
Capacity
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Warranty:
12 Months
Highlight:

rotary evaporator distillation

,

rotary vacuum film evaporator

,

quickly lift rotary glass evaporator

Product Description

Vacuum Rotary evaporator

A rotary evaporator is a device used in Chemical Laboratories for efficient and gentle removal of solvents from samples by evaporation.
The main components of a rotary evaporator are:
The motor unit which rotates the evaporation flask containing sample material.
A vapour duct which acts as an axis for sample rotation, and a vacuum tight conduit for the vapour being drawn off of the sample.
A vacuum system (not integral part of the equipment) to substantially reduce the pressure within the evaporator system.
A heated fluid (water / thermic fluid) bath to heat the sample being evaporated.
A condenser with double coil through which the coolant passes.
A condensate collecting flask at the bottom of the condenser, to collect the distilling solvent after it recondenses.
A mechanical or motorized mechanism to quickly lift the evaporation flask from the heating bath or lower the heating bath so that the evaporation flask does not remain in contact with bath.

Features

Adopt Japanese Technology AC induction motor, variable speed, no brush, no spark, can work effectively for a long time.
Chassis, bath pot, main bar, shaft of rotary evaporator are made of high qualified stainless steel, appearance is attractive and anti-corrosive.
Intelligent temperature control with digital display, can work with both water and oil bath, more widely used. Temperature fluctuation is only ±0.02 ℃. Evaporation is more stable and material can not be washed easily.
The series modular design on the whole set makes it extensible and easy to install, and more convenient to maintain.




Product Model

Evaporation Flask

Receiving Flask

Motor Power(w)

Bath Power

Rotation Speed

Evaporation Speed(L/h)

Power(V)

Dismension(cm)
PR-2
2L/29#
1L
40
1.5
10-180
1.2
220
55*35*75
PR-5
5L/50#
2L/3L
90
2
10-90
2
220
55*35*110
PR-10
10L/95#
5L
120
3
5-110
3.5
220
100*50*180
PR-20
20L/95#
10L+5L
120
5
5-110
5
220
110*70*200
PR-50
50L/125#
10L+10L
180
5
5-110
8
220
120*80*220

Product Details

10 20l 50l Rotary Evaporator Distillation Motorized Mechanism High Safety 0

10 20l 50l Rotary Evaporator Distillation Motorized Mechanism High Safety 1

10 20l 50l Rotary Evaporator Distillation Motorized Mechanism High Safety 2





Packing and delivery

10 20l 50l Rotary Evaporator Distillation Motorized Mechanism High Safety 3

Flexible and multiply shipping methods for on-time shipment:

The glass parts will be wrapped with foam material,then put into the carton, all parts will be packed into wooden case finally; Customized packaging can be available.
The damage caused by the transportation problem shall be born by the seller.


Our factory



10 20l 50l Rotary Evaporator Distillation Motorized Mechanism High Safety 4

We are a manufacturer and trader specialized in research, development and production of chemical glass instrument.



Main products include glass reactor, wiped film evaporator, rotary evaporator, short-path molecular distillation device and chemical glass tube.



Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching America, Mexico, India, Turkey, Germany and Norway.



Besides this, we also build the relationship with more than 10 oversea agents.



Our services

Warranty
We offer 1 years warranty . For the manufacturing and quality problem, we offer replacement, maintenance service.
The damage caused by the transportation shall be borned by the seller.

Could you do customized for us?
We are a manufacturer that can provide all kinds of customized services.

If you have questions of the equipment
Please send us email of the problem. Pictures or a small video will be much better. We will find the
problem and tell you how to solve it. If there is a broken, we will send you a new part, and it is free in the warranty period.


Tags:

rotary evaporator distillation,

rotary vacuum film evaporator,
