Agitating Lab Glass Reactor , Double Layer Glass Reactor With 3 Way Cow Adapter

Agitating Lab Glass Reactor , Double Layer Glass Reactor With 3 Way Cow Adapter

MOQ: 1 set
Price: Negotiable
Standard Packaging: The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case.
Delivery Period: within 5days after payemnt received
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 500 sets/momth
Detail Information
Place of Origin
CHINA
Brand Name
NTSJ
Certification
CE,ISO9001
Model Number
FPGR-20
Application:
New Material Synthesis
Type:
Reaction Kettle
Warranty:
12months
Material:
3.3 Borosilicate Glass
Stock:
In Stock
Certification:
CE/ISO
After-sales Service Provided:
Video Technical Support、Field Maintenance And Repair Service
Vacuum Degree:
-0.098mpa
Automatic Grade:
Semi-Automatic
High Light:

jacketed glass vessel

,

double layer glass reactor

Product Description

Glass Reactor

PTFE flush discharge valve: No-sample accumulation in valve during operation and discharge.
Side discharge valve (standard or preload): No dead angle, air isolated discharge.

Glass reactor lid could be customized.

ISO & CE certification high quality guarantee.



Preload discharge valve is able to decrease flask crack risk due to improper over-screw of discharge valve.

Adapter of glass reactor jacketed layer.
The liquid of the flow circulating pump or high & low temperature circulating pump will through the adapter firstly, and then into the glass reactor body, help to ease the pressure of the glass, finally prolong the service life of the glass body.





Product Model PGR-3 PGR-5 PGR-10 PGR-30 PGR-50 PGR-100 PGR-200
Volume(L) 3 5 10 30 50 100 200
Neck No.on Cover 4 5 6 6 6 6 6
External Diameter of Inner Vessel(mm) 150 180 230 330 365 460 600
External Diameter of Outer Vessel(mm) 200 230 290 365 410 500 650
Cover Diameter(mm) 150 180 265 265 265 340 340
Vessel Height(mm) 300 400 450 730 850 950 1200
Motor Power(W) 40 60 140 140 140 250 750
Vacuum Degree(Mpa) 0.098 0.098 0.098 0.098 0.098 0.098 0.098
Rotation Speed(rpm) 50-1400 50-600 50-600 50-600 50-600 50-600 50-600
Torque(Nm) 0.27 0.95 2.23 2.23 2.23 3.98 6.37
Power(V) 220 220 220 220 220 220 220
Dimension(mm) 320*350*900 450*450*1200 650*650*1900 700*500*2100 800*600*2300 1000*700*2700 1200*900*3200



Main features

Customizable

All flasks are made of 3.3 borosilicate glass
Vacuum-jacketed distillation adaptor
Carefully designed 3-way cow adapter
The cold trap protects the vacuum pump from contamination and damage of vapors.
For organic chemistry labs, distillation, fractional distillation, separation, purification, and synthesis.

Agitating Lab Glass Reactor , Double Layer Glass Reactor With 3 Way Cow Adapter 0

Our factory

We are located in Nantong City,2 hours away drives from Shanghai.



Covering an area of sixteen thousand square meters, now we have over one hundred employees, boast an annual sales figure that exceeds US dollars twenty million.



Advantage of us is customize according to client need. We can provide relevant industry with design, manufacturing, equipment selection, instrument supporting, installation, debugging, maintenance.



Our chemical glass instruments have been widely used in the fields of pharmaceuticals, chemicals, biological pharmacy, new material, noble material.

Agitating Lab Glass Reactor , Double Layer Glass Reactor With 3 Way Cow Adapter 1

Packing and delivery

Flexible and multiply shipping methods for on-time shipment.


We have good cooperation with many international express companies, such as DHL/ UPS/ FedEx/ TNT and other, as well as large shipping companies providing air shipping and sea shipping.


Strict packing process to ensure the safety and completeness of the goods.



Agitating Lab Glass Reactor , Double Layer Glass Reactor With 3 Way Cow Adapter 2

Our service

Customizable

Post-sales direction on product application: Offer free guidance on products operation, help user to improve research accuracy, efficiency and extend product service life by much.

Repair and maintenance support: Strong ability on remote trouble shot guidance. Oversea buyers are able to solve problem in short time.

Rich parts supply : Rich parts available even for past instruments.



Professional consultation service on System Configuration to meet user's real needs.

We offer experimental site for buyers with special needs, do experiment with customers so to ensure suitability

production & On-time delivery: Products are test by many indexes before shipping, Lead time will be strictly controlled.
